DLS 4-channel amplifier CCi44

Reference Series - CCi44
One of the most versatile and great sounding 4-channel amplifiers on the market.

Historically, DLS CC series amplifiers have been considered by many to be the best sounding amplifiers in their price range! So - when we decided to release the CCi generation we had
much heritage to honor. After a long development process together with Gordon Taylor, we are very pleased that DLS has made another breakthrough in the field of compact audio for your car.

We started with new precision tooling of the heatsink that allowed for more heat dissipation fins on the outside, including updated optics with beveled edges.
But as always - it's the inside that counts - on the inside of the heatsink there is a large area of small fins that capture the heat from the air passing through the integrated
fan is pressed through the circuit board and released through thin slots in the side panels. Thanks to the optimized power supply section, the new CCi series produces more power and less heat!

From a sonic perspective, the new circuit has been further refined with linear controls now powering the preamp circuitry and high bias drive circuitry, combined with top quality Sanken
output devices that are sonically superior. The result is shimmering details combined with warm mids and an industry-leading S/N ratio of over 110dBA!

For perfect system integration, it includes the proven DLS High Level converter with Auto Start for a serious upgrade of OEM radios and a wide input level.
A useful feature of the High Level input in CCi44 is that a low-level output to additional amplifiers can be obtained via the RCA input connectors.



Number of channels - 4
Amplifier dungeon class - AB
Mono bridge mode 4 ohm - 2 x 220 Watt
Output power into 2 ohms - 4 x 110 Watts
Output power into 4 ohms - 4 x 85 Watts
Damping factor >300
THD at 5W, 20 Hz - 20 kHz. <0.25%
S/N ratio, A-weighted >110 dB
Frequency range 10 Hz - 60 kHz
Input sensitivity 1 - 4 Volts
Input impedance 6 kohm
Input impedance, high level 45 ohms
High pass filter 50 - 500Hz
Low-pass filter 50 - 500Hz
Power consumption (idle) 0.7 A
Power consumption (max) 64 A
High level input with automatic start Yes
Integrated fan
Dimensions (W x D x H) 129 x 320 x 55 mm (5.1? x 12.6? x 2.2?)
Weight 2.4 kg

Suitable for:
4-Channel

---

Output	440 watt
Number of channels	4
Guarantee	2 years
